Boyle Law Apparatus Manufacturer,Supplier and Exporter in India
Product Code : JA-H-7993
This Boyle's law apparatus lets students read pressure and volume together as they compress a trapped sample of air. A syringe and a pressure gauge are joined by a high-pressure hose on a sturdy Perspex board. Each reading is quick to take and easy to repeat, for gas law practicals at constant temperature.
Specifications of the Boyle's law apparatus with gauge
| Product code | JA-H-7993 |
|---|---|
| Type | Boyle's law apparatus |
| Pressure measurement | Pressure gauge |
| Gas container | Syringe |
| Connection | High-pressure hose between gauge and syringe |
| Mounting | Sturdy Perspex board |
| Manufacturer | JaincoLab, Ambala, India |
Gas law practicals with the Boyle's law apparatus
- Verifying Boyle's law. Set a starting volume on the syringe, compress the air in steps and read the gauge at each step. Check the air temperature on a room thermometer to show it stayed steady.
- Working out absolute pressure. Read the day's air pressure on a Fortin's barometer. If the gauge reads zero when open to the air, add this value to each reading.
- Plotting the results. Plot pressure against volume, then pressure against 1/volume. Find the constant from the gradient of the straight line.
- Explaining the dial. Use a Bourdon gauge to show the class how a curved tube moves a pointer as the pressure inside it rises.
Frequently Asked Questions
Why should the plunger be moved slowly?
Squeezing air quickly warms it, and Boyle's law needs a steady temperature. Move the plunger in small steps and pause before each reading, so the air settles back to room temperature.
Does the gauge show the full pressure of the trapped air?
Check it with the syringe open to the air. If it reads zero, it shows pressure above atmospheric. Add the day's atmospheric pressure to every reading to get the absolute pressure that Boyle's law uses.
What graph should students plot?
Pressure against volume gives a curve. Absolute pressure against 1/V gives a straight line through the origin. This shows that pressure times volume stays the same for a fixed mass of air at constant temperature.
How can I tell if the apparatus is leaking?
Set a volume, note the pressure and leave it for a while. If the reading falls or the plunger creeps back, air is escaping. Check the hose connections at the gauge and the syringe.
Why take readings while releasing the plunger as well?
Readings taken on the way up and on the way down show whether friction or warming has affected the results. Average the two readings for each volume before you plot the graph.
What should I do if the plunger sticks?
A sticking plunger makes the volume jump and the readings uneven. Keep the syringe clean and dry and move the plunger gently. If it stays stiff, pass it to the lab technician rather than forcing it.
