Dial Gauge Manufacturer,Supplier and Exporter in India
Product Code : JA-CLE-9105
The Dial Gauge (SKU JA-CLE-9105) is a 10 mm range dial indicator graduated in 0.01 mm, supplied with a switchable magnetic base, brackets and attachments in a fitted case, for measuring run-out, flatness and small displacements. This dial gauge with magnetic base has a 60 mm dial and a 0-50-0 reading. It is supplied by JaincoLab for metrology labs and machining workshops in ITI, polytechnic and engineering colleges.
Specifications
The Dial Gauge has a 10 mm range, 0.01 mm graduation, 0-50-0 reading and a dial of about 60 mm, with a hardened and ground contact point, stainless steel spindle, rack and pivot, and a rotatable dial and bezel for zero setting through 360 degrees.
| Product | Dial Gauge |
| SKU | JA-CLE-9105 |
| Range | 10 mm |
| Graduation | 0.01 mm |
| Reading | 0-50-0 |
| Dial diameter | 60 mm approx. |
| Contact point | Hardened and ground |
| Spindle, rack and pivot | Stainless steel |
| Zero setting | Dial and bezel rotatable through 360 degrees |
| Magnetic base | Permanent magnet, push-button on/off, 3 energised sides; base approx. 80 x 55 x 55 mm; column 25 mm diameter |
| Supplied with | Brackets, attachments and fitted case |
Applications of the dial gauge with magnetic base
Clamped to a machine or surface plate by its magnetic base, the dial gauge shows small movements directly, so students can measure run-out, check alignment and compare parts against a setting.
- Measuring run-out of shafts between centres or in a lathe chuck
- Checking flatness and parallelism on a surface plate
- Aligning work and vices on machine tables
- Comparative measurement in metrology practicals
- Machinist training in ITI, polytechnic and B.Tech labs
Scope of supply and ordering
The listing covers one dial gauge with magnetic base, brackets and attachments in a fitted case, as described above.
The Dial Gauge is supplied for single laboratories as well as bulk orders for colleges, polytechnics and training institutes.
Frequently asked questions
What is the range and graduation?
10 mm range with 0.01 mm graduation and a 0-50-0 reading.
Is a magnetic base included?
Yes. A permanent-magnet base with push-button on/off and three energised sides is supplied.
How is zero set?
The dial and bezel rotate through 360 degrees for zero setting.
Related products
Browse the full mechanical engineering lab equipment range from JaincoLab, including workshop hand tools and metrology.
Request a quote
Request the price and specification sheet for the Dial Gauge through the JaincoLab contact page; mention SKU JA-CLE-9105, the quantity and where it is to be delivered. Tender and project enquiries can be sent through the tenders page.
