Digital Respinometer Manufacturer,Supplier and Exporter in India
Product Code : JA-DR-2394
The Digital Respinometer (SKU JA-DR-2394) is a manometric respirometer that measures gas exchange, such as oxygen uptake, by cells, tissue slices or micro-organisms held in small flasks at a controlled temperature. This digital respirometer has a polished stainless steel water tank taking 7 manometers a side, a digital temperature display and an oscillating drive of about 90 rpm that keeps the flask contents mixed. JaincoLab manufactures it for biochemistry, microbiology and pharmacology laboratories.
Specifications
The bath is a polished stainless steel tank with a stainless steel immersion heater and stirrer, controlled from 5 °C above ambient to 60 °C to within ±0.5 °C and shown on a digital display with 0.1 °C resolution.
| Product | Digital Respinometer |
| SKU | JA-DR-2394 |
| Tank | Polished stainless steel, 7 manometers a side |
| Temperature range | 5 °C above ambient to 60 °C |
| Temperature control | Within ±0.5 °C |
| Display | Digital, 0.1 °C resolution |
| Heater | Stainless steel immersion heater |
| Stirring | Stirrer for uniform temperature |
| Manometers | Mounted on graduated scale for reading pressure changes |
| Flasks | Flask with centre well and side flask attached to each manometer |
| Oscillation | Approx. 90 rpm |
| Exterior | Powder coated, with wheels |
Applications of the digital respirometer
Reading the pressure change in each manometer at constant temperature shows how much gas a sample takes up or gives off over time.
- Oxygen uptake of tissue slices and homogenates in biochemistry practicals
- Respiration rate of yeast, bacteria and other micro-organisms
- Effect of drugs, substrates and inhibitors on cellular respiration in pharmacology research
- Postgraduate and research work in biochemistry, microbiology and plant physiology
Scope of supply and ordering
The listing covers the respirometer with its stainless steel tank, immersion heater, stirrer, digital temperature controller, manometers on graduated scales, flasks with centre well and side flask, oscillating drive and wheeled powder-coated cabinet. The number of manometer sets supplied is confirmed on the quotation. Accessories, spares and quantities are confirmed on the quotation.
Minimum order quantity, lead time and packing are confirmed on each quotation for the number of units and manometer sets and the delivery destination. Single units for research and teaching laboratories and tender quantities are supplied.
Frequently asked questions
How many manometers does it take?
The tank takes 7 manometers a side.
What temperature range does it cover?
From 5 °C above ambient to 60 °C, controlled to within ±0.5 °C and displayed with 0.1 °C resolution.
How are the flask contents mixed?
The manometers oscillate at approximately 90 rpm, and a stirrer keeps the bath temperature uniform.
Related products
This model is listed in the JaincoLab digital respirometer range.
Request a quote
To order the Digital Respinometer, send the number of manometer sets, quantity and delivery destination through the JaincoLab contact page or email [email protected], quoting SKU JA-DR-2394. Buying under a laboratory tender? Use our tenders page.
