Inclined Metallurgical Microscope Manufacturer,Supplier and Exporter in India
Product Code : JA-M-990
The Inclined Metallurgical Microscope (SKU JA-M-990) is a binocular reflected-light microscope with a 45-degree head, used to examine polished metal surfaces and other opaque materials. Four flat field achromatic objectives from M4x to M40x sit on a quadruple nosepiece, and a 6 V 20 W halogen vertical illuminator with aperture diaphragm lights the specimen from above. Engineering colleges and polytechnic metallurgy laboratories use this inclined metallurgical microscope for student practicals.
Specifications
The listed specification is a binocular observation head inclined at 45 degrees, a quadruple revolving nosepiece, a 6 V 20 W halogen bright field vertical illuminator with aperture diaphragm, filter slots and bulb centring, flat field achromatic M4x, M10x, M20x and M40x objectives and WF10x and H5x eyepieces.
| Product | Inclined Metallurgical Microscope |
| SKU | JA-M-990 |
| Observation head | Binocular, inclined at 45 degrees |
| Nosepiece | Quadruple revolving |
| Illumination | Bright field vertical illuminator, 6 V 20 W halogen; aperture diaphragm, filter slots, bulb centring |
| Objectives | M4x, M10x, M20x, M40x, corrected for flat field achromat |
| Eyepieces | WF10x and H5x |
Applications of the inclined metallurgical microscope
In teaching laboratories it is used to observe the microstructure of polished and etched metal samples by reflected light; the extra M20x objective gives an intermediate step between low-power survey and M40x detail, which helps students locate and study features.
- Microstructure of steels and cast irons
- Phase identification in non-ferrous alloys
- Inspection of polished and machined surfaces
- Metallurgy practicals in engineering colleges
- Material testing courses in polytechnics
Scope of supply and ordering
One unit is one inclined metallurgical microscope with binocular head, quadruple nosepiece, halogen vertical illuminator, four flat field objectives and WF10x and H5x eyepieces. Stage details, filters, spare bulbs, accessories and quantities are confirmed on the quotation.
Packing, minimum order quantity and lead time depend on the order size and the delivery destination, and each is confirmed on the quotation. Bulk orders for school and college laboratories and tender supplies are handled, including export shipments to Africa, the Middle East and South and South-East Asia.
Frequently asked questions
Which objectives are supplied?
Four objectives, M4x, M10x, M20x and M40x, corrected for flat field achromat.
What total magnification does it give?
The total magnification depends on the eyepiece and objective used and is confirmed on the quotation for the set supplied.
How is the specimen illuminated?
By a bright field vertical illuminator with a 6 V 20 W halogen lamp, aperture diaphragm and filter slots.
