Site Dumper Manufacturer,Supplier and Exporter in India
Product Code : JA-WT-8792
The site dumper is an articulated four-wheel-drive dumper for moving concrete, soil and materials on construction training sites. It carries a 3000 kg payload in a 1500-litre hydraulic tipping skip, has a 40 hp water-cooled diesel engine (30 kW at 2300 rpm), a 5 + 5 gearbox, hydraulic steering, a 4.5 m turning radius and 12.5-16 tyres, and weighs 2250 kg (SKU JA-WT-8792).
Specifications
Listed specification:
| Product | Site Dumper |
| SKU | JA-WT-8792 |
| Chassis | Articulated frame |
| Drive | 4 x 4 |
| Engine | Diesel, 40 hp, water cooled, 30 kW at 2300 rpm |
| Gearbox | Heavy duty, 5 + 5 |
| Payload | 3000 kg |
| Skip capacity | 1500 litres |
| Tipping | Hydraulic tipping hopper |
| Steering | Hydraulic |
| Turning radius | 4.5 m |
| Tyres | Four, 12.5-16 |
| Weight | 2250 kg |
Scope of supply and ordering
The listing covers one site dumper, supplied by JaincoLab. Quantities, packing and lead time are confirmed on the quotation.
Frequently asked questions
What load can it carry?
A 3000 kg payload in a 1500-litre skip.
How is the skip emptied?
By a hydraulic tipping hopper.
What engine is fitted?
A 40 hp water-cooled diesel engine rated 30 kW at 2300 rpm.
Related products
The workshop tools range lists further items of this kind.
Request a quote
Quotations for the Site Dumper are prepared on request through the JaincoLab contact page. For tender or project supply, see our tenders page.
