Study of Logarithmic Amplifier Manufacturer,Supplier and Exporter in India
Product Code : JA-COA-1148
The Study of Logarithmic Amplifier apparatus (SKU JA-COA-1148) is used to build log and antilog amplifiers with an IC 741 and a diode in the feedback path, and to find the ideality factor of the log amplifier. For the antilog amplifier students plot a graph of V1 against V0. The circuit uses a potentiometer and a 4007 or OA 79 diode, with a continuously variable +/-15 V DC regulated supply protected against short circuit and overload.
Specifications
Parts and supply as listed:
| Product | Study of Logarithmic Amplifier |
| SKU | JA-COA-1148 |
| IC | 741 |
| Diode | 4007 / OA 79 |
| Other parts | One potentiometer |
| Power supply | +/-15 V DC regulated, continuously variable, short circuit and overload protected |
| Meter | DMM named in the listing |
| Experiments | Log and antilog amplifier, ideality factor, V1-V0 graph |
Scope of supply and ordering
The listing names a DMM with this apparatus; whether it is included is stated on the quotation along with quantities and packing.
Frequently asked questions
What can be studied on the logarithmic amplifier apparatus?
Log and antilog amplifiers, the ideality factor of the log amplifier and a V1-V0 graph for the antilog amplifier.
Which diode and IC are used?
An IC 741 with a 4007 or OA 79 diode.
Related products
- Study of Instrumentation Amplifier
- Study Characteristics of Operational Amplifier
- Study of Operational Amplifier
- Study of Operational Amplifier as V to I to I to V Convertor
The op-amp apparatus range is listed in our scientific instrument range.
Request a quote
For the logarithmic amplifier apparatus, send the quantity through our contact page. For tender or project supply, see our tenders page.
