Equipment Kit for Demonstrating Electrical Experiments Manufacturer,Supplier and Exporter in India
Product Code : JL-GLE-11276
The Equipment Kit for Demonstrating Electrical Experiments, SKU JL-GLE-11276, is a JaincoLab diode and transistor experiment kit for school electronics. It pairs common components, a 2N2222 NPN transistor, a 5.1 Zener diode, two 1N4007 rectifier diodes and 1K and 100K resistors, with a circuit board that takes 4 mm leads, a DC voltmeter (0-10 V), an ammeter (0-5 A), a digital multimeter and a 22 ohm, 3.3 A rheostat, so students can build and measure simple semiconductor circuits.
Specifications
Components listed:
| Product | Equipment Kit for Demonstrating Electrical Experiments |
| SKU | JL-GLE-11276 |
| Cat. No. | JSS-367/017 |
| Transistor | 2N2222, NPN |
| Zener diode | 5.1 (as listed) |
| Diodes | 2 x 1N4007 |
| Resistors | 1 x 1K; 3 x 100K |
| Circuit board | For 4 mm plug cables |
| Meters | DC voltmeter 0-10 V; ammeter 0-5 A; digital multimeter |
| Rheostat | 22 ohm, 3.3 A |
| Other | Metal ruler, push-button switch, universal clamp |
Experiments with the kit
Circuits students can build:
- Forward and reverse bias of the 1N4007 diode
- Voltage regulation with the 5.1 Zener diode
- The 2N2222 transistor as a switch
- Current and voltage measurements with the rheostat and meters
Scope of supply and ordering
The kit is supplied with the components, board, meters, rheostat and accessories listed; connecting leads and kit numbers are confirmed on the quotation.
Frequently asked questions
Which transistor is included?
A 2N2222 NPN transistor.
Which diodes come with the kit?
Two 1N4007 diodes and one 5.1 Zener diode.
What are the meter ranges?
DC voltmeter 0-10 V and ammeter 0-5 A, plus a digital multimeter.
Related products
Electrical and electronics apparatus is in the JaincoLab general lab equipment range.
Request a quote
Request pricing for the electrical experiments kit (JL-GLE-11276) via the contact page.
