Spring Testing Machine Manufacturer,Supplier and Exporter in India
Product Code : JA-SOMLE-8906
The Spring Testing Machine (SKU JA-SOMLE-8906) is a spring testing machine for load-deflection tests on tension and compression springs, carried out accurately and quickly. A compact base carries two fixed uprights and four horizontal plates, and a hydraulic unit housed in a cabinet applies the load, with the pump hand wheel and release valve handle outside for easy operation. Maximum capacity is 500 kg (5000 N). It is supplied by JaincoLab for strength of materials labs.
Specifications
The machine has a maximum capacity of 500 kg / 5000 N, tests tension and compression springs, takes tension springs up to 300 mm free length and compression springs up to 200 mm diameter, and resolves force to 0.1 kg / 1 N.
| Product | Spring Testing Machine |
| SKU | JA-SOMLE-8906 |
| Maximum capacity | 500 kg / 5000 N |
| Type of spring | Tension and compression |
| Free length of tension spring | 300 mm |
| Diameter of compression spring | 200 mm |
| Load application | By top hand wheel; hydraulic unit in cabinet |
| Maximum crosshead travel (without sample/grip) | 500 mm |
| Force measuring resolution | 0.1 kg (100 g) / 1 N |
| Frame | Compact base, two fixed uprights, four horizontal plates |
Applications of the spring testing machine
Students load a spring in steps and record deflection, then use the load-deflection graph to find the spring stiffness and modulus of rigidity of the spring material.
- Load-deflection test on compression springs
- Load-extension test on tension springs
- Spring stiffness (spring rate)
- Modulus of rigidity of spring wire
- Strength of materials practicals in B.Tech, diploma and ITI courses
Scope of supply and ordering
The listing covers the spring testing machine with its hydraulic loading unit as described. Sample springs and grips are confirmed on the quotation.
Frequently asked questions
What is the maximum capacity?
500 kg, which is 5000 N.
Which springs can be tested?
Tension springs up to 300 mm free length and compression springs up to 200 mm diameter.
What is the force resolution?
0.1 kg (100 g), or 1 N.
